The spring-cleaning continues! When I originally prototyped Relocatable OCaml, it was during the OCaml 4.13 development cycle. The focus for the work originally was always about multiple versions of the compiler co-existing without interfering with each other, so even the early prototypes were done on both OCaml 4.12 and OCaml 4.13. In fact, I see that in this talk, I even demo’d it on both versions. My intention from the start had always been to be able to provide either backports or re-releases of older compilers, on the basis that it would be tedious to have only the latest releases of OCaml supporting the various fixes, given that the failing CI systems which had motivated the project would continue to test older versions for several/many years after completion. In 2021, OCaml 4.08 (from June 2019) was still a recent memory. From a technical perspective, OCaml 4.08 was a very important release. It’s the first version of OCaml with a reliably namespaced Standard Library (the Stdlib module, though introduced in 4.07, had various issues with shadowing modules which weren’t completely addressed until 4.08). For my work, it was the version where we switched the configuration system to autoconf, and thus introduced a configuration system for the Windows ports. It provided a natural baseline in 2022 for the backports, and thus the workshop demonstration I gave in Ljubljana featured Windows and Linux for OCaml 4.08-4.14 as well as preview of OCaml 5.0.

Wind forwards 3¼ years, and OCaml 4.08 is certainly a distant memory, but the features in it means it is very much a baseline at the moment. So, partly because the work is mostly already done, partly because it’s the last piece of the Relocatable puzzle, and mainly because I think it will be useful, I’ve been working towards proposed branches to allow us to make some exceptional releases in these old branches.

OCaml 5.x means that we have already been maintaining OCaml 4.14 as an LTS release of OCaml (although the changes coming in OCaml 5.5 mean that we really will be looking to end that long-term support before too much longer). I’ve previously talked about synchronising the GitHub Actions workflows. and the crazy shell script that manages the backporting.

So, how do you maintain some 20-or-so in-flight PR branches being occasionally rebased forwards onto updated versions of OCaml and simultaneously backported on to, initially, 7 compilers and, by the end, 12 compilers? The answer is: carefully, and with a lot of automation! ‘Carefully’ entailed setting some important ground rules: for example, the golden rule was that either the work was rebased or it was being amended. Never both simultaneously. This rule meant that while effort may be required to rebase forwards, the backports remained fixed, which allowed the patch resolutions to re-settle. In order to ease the automation, it also occasionally required over-backporting, i.e. taking some changes back to old compilers which were not strictly necessary, but which meant that the main branches did not need to be extensively re-written.

Anyway, included in this back-porting was enough work to be able to get CI running, since once we’ve finished support for a given version, the branch is mostly left to gather dust.

Opening up old release branches

Image from Pinterest.

Like getting a stately home ready for visitors, the task I spent this week accomplishing was removing the dust sheets from the CI configurations on these old branches (4.08-4.13) so that the final backported changes could be properly tested. The stacks for Relocatable OCaml had these patches ordered as:

  1. Unify CI workflows (affecting 4.08-4.13). We started switching over to GitHub Actions during the 4.12 dev cycle, but only completed the migration during the 4.13 dev cycle, so there were long-dead Travis CI scripts in the 4.08-4.12 branches, and the 4.13 branch’s GitHub Actions scripts hadn’t of course received the updates which the 4.14 ones had.
  2. macOS arm64 support (4.08, 4.09 and 4.11). The curious gap is because Apple released the M1 during the 4.11 dev cycle, and it was decided that it was too late to alter the 4.11.0 release, so a re-release of 4.10 was done with Apple Silicon support, and then 4.12.0 “naturally” had the support, as the version of trunk to which it had originally been merged. As it happens, the 4.12 patches apply completely trivially to 4.11 and the 4.10 version of the patches apply trivially to 4.08 and 4.09, which means that you can get the complete support matrix when working on Apple Silicon.
  3. Windows FlexDLL bootstrap overhaul (affecting 4.08-4.12). The main thing here is ocaml/ocaml#10135, which made the ability to build the Windows ports of OCaml somewhat easier. The lack of this branch is the reason why the support for Windows in opam-repository at the moment from ocaml/opam-repository#25861 only goes back as far OCaml 4.13. It’s not because it’s impossible, it just requires a lot of hardening in the opam packages to work around various deficiencies, and it’s actually just a configuration/build system change which backports really very easily as far as 4.08 (getting 4.07 and earlier working in opam on Windows is a daftness for another day).
  4. Required backports for Relocatable OCaml (actual changes in the runtime/compiler which must be present to support the main PRs).
  5. runtime-launch-info backport (from OCaml 5.2; ocaml/ocaml#12751)
  6. compiled-primitives backport (from OCaml 5.3; ocaml/ocaml#12896)
  7. in-prefix-test harness (from OCaml 5.5; ocaml/ocaml#14014)

Number 1 is exactly where I wanted it, but unfortunately the test harness sits on top of a large number of other changes, mainly because it was actually written well after all of them! So I got out my Git hammer and began to re-forge the commit series. It’s quite a set, but at the end of it, the difference between 4.08 and 4.14 in appveyor.yml, .github/workflows and tools/ci is a small set of trivially justifiable changes relating to actual differences between those two releases (for example, OCaml 4.08 still had the graphics library to test!). Ignoring changes that affect the build, configure and test systems only, it requires just three PRs to resurrect that branch:

… and that’s it!

On top of that unified CI, it’s then possible to backport the test harness, which then provides reliable installation testing for all the relocatable features. I’m almost certainly strange, but this was kind of fun to backport. By the time it gets back to 4.08, the commit message for the harness itself reads:

Deviations from original:
  - C stub added to the harness instead of backporting
    caml_sys_proc_self_exe
  - Compmisc.reinit_path used instead of updating Compmisc.init_path
  - Config.c_compiler_vendor avoided by instead exposing the constant as
    Toolchain.c_compiler_vendor
  - Config.asm_dwarf_version folded into toolchain.ml.in
  - Config.shebangscripts avoided by instead adding an additional
    --with- option to the harness and threading $(SHEBANGSCRIPTS) from
    the build system
  - Required parts of Bytelink.read_runtime_launch_info directly added
    to the test harness, instead of exposing the machinery in Bytelink.
  - Misc.Stdlib.String.to_utf_8_seq added directly to TestRelocation.
  - ocamlmklib -M exits with code 0
  - Standard Library functions added:
    - Bytes.{get_utf_8_uchar,set_utf_16le_uchar} (4.14)
    - Char.Ascii.is_letter (5.4)
    - In_channel.{fold,input}_lines (5.1)
    - In_channel.input_all (4.14)
    - In_channel.really_input_bigarray (5.2)
    - In_channel.{set_binary_mode,with_open_bin} (4.14)
    - Int.max (4.13)
    - List.{drop,take}_while (5.3)
    - List.find_map (4.10)
    - List.fold_left_map (4.11)
    - Option.exists (5.5)
    - Out_channel.{with_open_bin,with_open_text} (4.14)
    - Result.Syntax (5.4)
    - String.{starts,ends}_with (4.13)
    - Sys.{mkdir,rmdir} (4.12)
    - Sys.signal_to_string (5.4)
    - Uchar.utf_{decode_uchar,decode_length,16_byte_length} (4.14)
    - Unix.realpath (4.13)
  - OCaml 5.4 labelled tuples removed
  - Added the ability for Build/Prefix/Relative to be optional in
    TestRelocation
  - Prior to 5.4.0, ocamlrun -config didn't include entries in the
    search path coming from CAML_LD_LIBRARY_PATH
  - Prior to 5.3.0, the compiler added +flexdll to the search path even
    when -nostdlib is specified, which affects the relocation test when
    bootstrapping FlexDLL.
  - Prior to 5.3.0, ocamlcmt and ocamlobjinfo didn't support -vnum. The
    simplest thing in this instance is simply to skip the test of their
    binaries.
  - Prior to 5.3.0, the dynlink library included a complete copy of the
    Config module, which affects the relocation test.
  - Prior to 5.2.0, RNTM isn't always written to bytecode images when
    compiling with -custom. Heuristic altered to analyse the DLLS
    section instead.
  - Prior to 4.14.0, errors in #load don't create detectable script
    errors: toplevel test adapted to cope with this
  - Prior to 4.13.0, the MSVC port didn't translate -lfoo automatically
  - Adapt the toplevel test to deal with the presence of compiler
    plugins in ocamlnat
  - Link test updated to deal with different runtime behaviour for
    errors and the lack of -output-complete-exe, both of which changed
    in 4.10.0
  - Build system adapted (Makefile.common macros didn't support C files
    until OCaml 5.2; VPATH wasn't used until OCaml 5.1; win32unix/unix
    distinction until OCaml 5.0)
  - Misc.Style changed to Misc.Color (changed in OCaml 5.2) and uses of
    the inline_code and hint formatting changed to loc (since
    inline_code was also added in OCaml 5.2 and hint OCaml 5.1)
  - Removed compressed marshalling support, since that was added in
    OCaml 5.1
  - Read camlheader file instead of runtime-launch-info, and adapt the
    relocation test to deal with incorrect naming of two of the header
    files (fixed in 4.09.0)
  - OCAML_FLEXLINK scrubbed from the environment (removed in 5.2)
  - Updated to deal with all bytecode binaries being installed with
    debug information
  - Updated to deal with all bytecode/native versions of tools being
    installed (changed in 5.1)
  - Updated to deal with old installation layout for otherlibs
  - Updated handling for the bigarray library
  - Updated relocation test to deal with different use of debug flags
    from OCaml 4.12+
  - Order of rules in testsuite/in_prefix/Makefile.test updated for
    compatibility with the aged version of GNU make shipped on macOS
    (pattern rules triggered in the wrong order otherwise)

Next-up, having removed all those dust sheets: finalising the actual backports!
